工具原料

Python 2.7



安装环境

1、安装 Python 2.7

2、配置环境变量 Path :C:\Python27





python是否安装成功

3、检验python是否安装配置成功：打开cmd，输入python，如果出现以下界面，则说 明你的python安装成功了

4、安装第三方的模块  下载地址：

如果不能下载，或下载的文件是whl不知怎么打开，可下载我之前下载的：



切图脚本

创建一个文本，修改后缀为py，建议命名：unpack_plist.py，代码如下：

#!pythonimport os,sysfrom xml.etree import ElementTreefrom PIL import Imagedef tree_to_dict(tree):    d = {}    for index, item in enumerate(tree):        if item.tag == 'key':            if tree[index+1].tag == 'string':                d[item.text] = tree[index + 1].text            elif tree[index + 1].tag == 'true':                d[item.text] = True            elif tree[index + 1].tag == 'false':                d[item.text] = False            elif tree[index+1].tag == 'dict':                d[item.text] = tree_to_dict(tree[index+1])    return ddef gen_png_from_plist(plist_filename, png_filename):    file_path = plist_filename.replace('.plist', '')    big_image = Image.open(png_filename)    root = ElementTree.fromstring(open(plist_filename, 'r').read())    plist_dict = tree_to_dict(root[0])    to_list = lambda x: x.replace('{','').replace('}','').split(',')    for k,v in plist_dict['frames'].items():        rectlist = to_list(v['frame'])        width = int( rectlist[3] if v['rotated'] else rectlist[2] )        height = int( rectlist[2] if v['rotated'] else rectlist[3] )        box=(             int(rectlist[0]),            int(rectlist[1]),            int(rectlist[0]) + width,            int(rectlist[1]) + height,            )        sizelist = [ int(x) for x in to_list(v['sourceSize'])]        rect_on_big = big_image.crop(box)        if v['rotated']:            rect_on_big = rect_on_big.rotate(90)        result_image = Image.new('RGBA', sizelist, (0,0,0,0))        if v['rotated']:            result_box=(                ( sizelist[0] - height )/2,                ( sizelist[1] - width )/2,                ( sizelist[0] + height )/2,                ( sizelist[1] + width )/2                )        else:            result_box=(                ( sizelist[0] - width )/2,                ( sizelist[1] - height )/2,                ( sizelist[0] + width )/2,                ( sizelist[1] + height )/2                )        result_image.paste(rect_on_big, result_box, mask=0)        if not os.path.isdir(file_path):            os.mkdir(file_path)        outfile = (file_path+'/' + k).replace('gift_', '')        print outfile, "generated"        result_image.save(outfile)if __name__ == '__main__':    filename = sys.argv[1]    plist_filename = filename + '.plist'    png_filename = filename + '.png'    if (os.path.exists(plist_filename) and os.path.exists(png_filename)):        gen_png_from_plist( plist_filename, png_filename )    else:        print "make sure you have boith plist and png files in the same directory"

使用方法

命令行： python unpack_plist.py  plist文件名称

比如： python unpack_plist.py  ui (我的plist文件全名为 ui.plist)
